The POE21U1AF-EUK from Pelco is a single port power injector is designed to meet the demanding data rate and power requirements of IP cameras with high-quality streaming video capabilities. The injector offers a total output power of 19.6 W, which meets the IEEE802.3af standard for detection, connection, disconnection, and fault protection.

The POE21U1AF-EUK power injector is compatible with 10/100Base-T systems and systems up to 1000 Mbps. AC input voltage ranges from 100 to 240 VAC with input frequency from 47 to 63 Hz. Maximum output load current is 350 mA at 56 VDC.

Features

• Fully Compliant Detection, Disconnect, Overload and Voltage Control (IEEE802.3af)
• Diagnostic LEDs
• Full Protection
  – Overcurrent Protection (OCP)
  – Overvoltage Protection (OVP)
• Non-Vented Case
